Why choose BRE50.
The BRE50 is operated with compressed air only. The chute, moving slowly forward and fast backward, causes the scrap to move forward. Born to evacuate the scrap on the blanking molds and to transport metal components, it has found many sectors of application: metal molds in general, plastic molds, mechanical, food, pharmaceutical, and assembly industries.
BRE50 SCRAP REMOVAL SYSTEM
Features and technical data.

  • Only 27 mm high

  • Minimum compressed air consumption

  • Strong against uneven loads

  • It carries downhill and onto the plane

  • Compact size

  • Maximum load (including slide): 50 kg

  • Supply fluid: filtered, non-lubricated, non-humid compressed air

  • Working pressure (bar): Min 3 / Max 6

  • Working temperature: Min 0 ° C / Max 60 ° C

  • Mounting inclination: Min 0 ° / Max -45 °

  • Noise dB (A): 60

Download brochure
All advantages.

  • Easy assembly and use

  • Easy frequency adjustment in small spaces

  • Application of more chutes on the same scrap remover

  • Low initial cost

  • Minimum maintenance

  • Long life

  • Reliable

  • No electricity required

  • No belt replacement as on belt conveyors

  • It also works with different inclinations

  • Compliant with RoHS2 directive in respect of the environment

  • In stock

AREAS OF APPLICATION
AND ACCESSORIES
The advanced BRE50 technology is designed to ensure optimal performance in different areas of use, while also offering extra safety thanks to additional accessories.
Fields of application

  • Removing scraps from stamping dies

  • Metal components transport

  • Separation and sieving of different elements (e.g. small metal parts)

  • Mechanical industry

  • food industry

  • Pharmaceutical industry

  • Automation

Greater safety thanks to BRE-CD sensor

The BRE scrap removal system is a necessary component in the stamping process but it can also pose risks: if it stops working, the scraps keep gathering and may cause damages to the tools.

How it works: BRE-CD is a sensor that detects when the scrap remover stops during the production process and gives an alert signal by an alarm connected to it.
